PORTCONNECTIONDISPLAYMONITORMOUNTING

Fig.2Fixingthemonitor

Monitorsupport

4

5

Angleadjustment

screw

Monitorsupport

Fig.1Mountingthesupport

Mountingsurface

Supportmountingscrew

Springlockwasher

Sunshield

Fig.3Portconnection

1

2

3

4

5

6 7

1.Videooutput

2.Camera1input

3.Camera2input

4.Audiooutput

5.Toexteriorspeaker

6.Normal/Mirrorimageswitch

7.Powerinput

Blacktoground(GND)

Redtopowersupply

Orangetoreversinglight

Whitetodimmer

Detailofports

Port7/POWER

Port2/C1

GND(ground)

Powerofcamera

Videoinput

Audioinput

Mirror

Normal

1

2

ON

Turntheswitchfromuptodowncanswitchtheimage

displayfrommirrortonormal.

Port6/MIRROR

5
